(In the above figure, the cathode rays pass from the cathode at the rear part of the tube, striking the front glass and making it glow green by the fluorescence. Hence, cathode rays carry electric current through the tube. After reaching the anode, electrons pass through the anode wire, present to the power supply, and then return to the cathode. Researchers observed that the objects placed inside the tube in front of the cathode could cast a shadow on the glowing wall and realized that something (a kind of ray) must be travelling from the cathode in straight lines. Cathode rays are invisible, but when they reach the glass wall of an early vacuum tube, they excite the atoms and cause them to emit light, which is known as fluorescence. The high velocities of these low mass particles are accelerated by the voltage applied between the electrodes. They also travel in straight lines via an empty tube. Since electrons hold a negative charge, they are attracted to the positive anode and repelled by the negative cathode. The increased random heat motion of the filament knocks electrons out of the filament's surface and into the tube's evacuated space. Modern vacuum tubes often use thermionic emission, in which the cathode is a thin wire filament heated by a separate electric current flowing through it. The ions that are positively charged accelerated with an electric field towards the cathode, and when they collided with it, they knocked the electrons out of its surface. Crookes tubes were the first cold cathode vacuum tubes, and they worked by ionising the remaining gas atoms in the tube between the cathode and the anode using a high electrical potential of thousands of volts. To bring the electrons into the tube, they must first be isolated from the atoms in the cathode. In 1927, Germer and Davisson used a crystal lattice to specifically illustrate the cathode rays' wave-like behaviour.Ĭathode rays are so-named due to the reason they are emitted by the negative cathode or electrode in a vacuum tube. Later in 1924, Louis de Broglie showed in his doctoral dissertation that, in fact, electrons are much like photons in the respect that they act both as particles and as waves in a dual manner as Albert Einstein had shown for light earlier. Also, these can create fluorescence, mechanical effects, and more. Since scientists knew it was difficult to deflect electromagnetic waves with an electric field, this was evidence that the beams were made up of particles. This debate between them was resolved when an electric field was used to deflect the rays by J. Also, Crookes insisted it was a particle, while Hertz maintained it as a wave. These conflicting properties have caused disruptions when trying to classify it either as a particle or wave.
Ernest Rutherford has demonstrated that the rays could pass through the thin metal foils, the behaviour expected of a particle. Like a wave, the cathode rays travel in straight lines and form a shadow when obstructed by the objects. This particular effect, when coupled with the controlled deflection of a cathode ray either by a magnetic or electric field, the cathode-ray oscilloscope (rather than the cathode-ray tube CRT) is used to track the values and changes of an alternating current or voltage, as well as the image tube used in radar and television.
When cathode rays collide with particular molecules used to cover a cathode plate, the molecules (and thus the screen) emit light. X-rays or a very high temperature are created by cathode rays centred on a hard target (anticathode) on a small object in a vacuum (cathode-ray furnace). A cathode ray is defined as a stream of electrons leaving the negative electrode (or cathode) in a discharge tube that contains gas at low pressure or the electrons emitted by the heated filament in certain electron tubes.
